It's all about the way things run.
Precision as a matter of principle.
When it comes to drawer runners for furniture drawers, the variety of Hettich products is unbeatable. The precise Actro 5D runner and the versatile Quadro runner provide the best solution for convenient and reliable drawer opening and closing for all furniture classes and loads.
Our reliable runner systems for wooden drawer boxes
Actro
Quadro
Quadro
The Actro drawer runner is simply the perfect choice for unique furniture design, narrow reveals and large front panels. It offers maximum adjustment tolerance and front panel reveal alignment meets the most exacting demands. Excellent running performance and incredible stability provide supreme quality you can feel and hear.
Quadro
Quadro
Quadro
Quadro drawer runners guarantee high level of drawer convenience. With attractive design from concealed installation. With long life and constant top performance. The robust tracks provide the steel balls with optimum control - for gratifying vertical and lateral stability. The comprehensive range with many user friendly functions provides powerful solutions as a cost effective basis for tapping into various furniture segments.
Actro 5D 500mm Silent System
Unequalled running action and exceptional stability with extremely low opening and closing forces and unbeatable adjustment.
SKU: HE9318256 (L)
SKU: HE9318258 (R)
- Full extension runner for combining with wooden drawer with catches
- Integrated Silent System
- Tool-less height adjustment up to + 3mm, side adjustment up to +/- 1.5 mm, tilt adjustment up to + 4 mm and radial adjustment up to +/- 1.5 mm
- Optional Push-to-open Silent
- Load class: 40 kg
- Galvanised steel
Actro 5D Catches, left and right (required)
Required to attach the Actro Runners to the drawer box
SKU: HE9320334 (L)
SKU: HE9320335 (R)
- Tool-less, intuitive side adjustment up to +/- 1.5 mm
- Height adjustment up to + 3 mm
- Die-cast zinc, plastic, anthracite
Push to open Silent opening system (optional)
Required when wanting the optional push-to-open feature
SKU: HE9257892
- Can be used with wooden drawer on Actro YOU with Silent System
- Optional synchronisation possible
Push to open synchronisation bar (optional)
Useful for wider drawers when optimal push synchronisation is required
SKU: HE 9236718
- For cutting to length, length 2000 mm
- Extension / optional connector for minimising offcut waste
Anti-slip mat (optional)
An optional solution to prevent drawer contents from moving
SKU: HE9209580
- For inserting into the drawer or pot-and-pan drawer
- Can be cut to length
- 5m roll
- Plastic
Actro YOU 500mm Silent System
Unequalled running action and exceptional stability with extremely low opening and closing forces.
SKU: HE9256992 (L)
SKU: HE9256993 (R)
- Full extension runner for combining with AvanTech YOU system drawer or wooden drawer with catches
- Integrated Silent System
- Optional: Push to open Silent
- Load class 40 kg
- Load capacity to EN 15338, Level 3
- Galvanised steel
Actro YOU Catches, left and right (required)
Required to attach the Actro Runners to the drawer box
SKU: HE9257263 (L)
SKU: HE9257264 (R)
- For using Actro YOU with wooden drawers
- Height adjustment up to + 3 mm
- Die-cast zinc, plastic, anthracite
Push to open Silent opening system (optional)
Required when wanting the optional push-to-open feature
SKU: HE9257892
- Can be used with wooden drawer on Actro YOU with Silent System
- Optional synchronisation possible
Push to open synchronisation bar (optional)
Useful for wider drawers when optimal push synchronisation is required
SKU: HE 9236718
- For cutting to length, length 2000 mm
- Extension / optional connector for minimising offcut waste
Anti-slip mat (optional)
An optional solution to prevent drawer contents from moving
SKU: HE9209580
- For inserting into the drawer or pot-and-pan drawer
- Can be cut to length
- 5m roll
- Plastic
Quadro YOU 350mm - 500mm Silent System
Unequalled running reliability with all the stability one expects from a high-quality, easy-to-install drawer runner.
500mm
SKU: HE9256872 (L)
SKU: HE9256873 (R)
450mm
SKU: HE9256868 (L)
SKU: HE9256869 (R)
400mm
SKU: HE9256864 (L)
SKU: HE9256865 (R)
350mm
SKU: HE9256860 (L)
SKU: HE9256861 (R)
- Full extension runner for combining with AvanTech YOU system drawer or wooden drawer with catches
- Integrated Silent System
- Tool-less height adjustment up to + 3 mm
- Load class 30 kg
- Suitable for drawers with a side profile thickness of up to 16 mm
- Load capacity to EN 15338, Level 3
- Galvanised steel
Quadro YOU Catches, left and right (required)
Required to attach the Actro Runners to the drawer box
SKU: HE9257260 (L)
SKU: HE9257261 (R)
- For using Quadro YOU with wooden drawers
- Height adjustment up to + 3 mm
- Plastic anthracite
Anti-slip mat (optional)
An optional solution to prevent drawer contents from moving
SKU: HE9209580
- For inserting into the drawer or pot-and-pan drawer
- Can be cut to length
- 5m roll
- Plastic
Quadro YOU 400mm & 500mm Push-To-Open
Unequalled running reliability with all the stability one expects from a high-quality, easy-to-install drawer runner.
500mm
SKU: HE9256917 (L)
SKU: HE9256918 (R)
400mm
SKU: HE9256909 (L)
SKU: HE9256910 (R)
- Full extension runner for wooden drawer with catches
- Integrated Push to open opening mechanism
- Tool-less height adjustment up to + 3 mm
- Optional: synchronisation
- Load class M (30 kg)
- Suitable for drawers with a side profile thickness of up to 16 mm
- Load capacity to EN 15338, Level 3
- Galvanised steel
Quadro YOU Catches, left and right (required)
Required to attach the Actro Runners to the drawer box
SKU: HE9257260 (L)
SKU: HE9257261 (R)
- For using Quadro YOU with wooden drawers
- Height adjustment up to + 3 mm
- Plastic anthracite
Push to open synchronisation bar (optional)
Useful for wider drawers when optimal push synchronisation is required
SKU: HE9236718
- For cutting to length, length 2000 mm
- Extension / optional connector for minimising offcut waste
Push to open trigger (optional)
One sided adapter type A for connecting synchronisation to Quadro drawer runners with Push to open
SKU: HE 9219966
Anti-slip mat (optional)
An optional solution to prevent drawer contents from moving
SKU: HE9209580
- For inserting into the drawer or pot-and-pan drawer
- Can be cut to length
- 5m roll
- Plastic
